FLYTO 1.2G 1.3G 1W VTX Long-Range FPV Video Transmitter with IRC Protocol

Main Features:

Channels: 8CH (8 channels available).

Control Protocols: Supports IRC Tramp protocol, compatible with OSD (On-Screen Display) parameter adjustment.

Power Output: Adjustable power levels - PIT, 25mW, 400mW, 800mW, and 1000mW.

Power Supply: Efficient DC/DC converter supports 7-36V input.

Audio Input: Supports external audio input.

Voltage Output: Provides 5V output for peripherals.

Product Specifications:

Transmitter (Airborne Unit):

Input Voltage: 7-36V DC (compatible with 2-6S LiPo batteries).

Output Voltage: 5V/0.5A (for powering cameras or other devices).

Weight: 10g (lightweight design).

Dimensions (L x W x H): 35.8mm x 22mm x 7.5mm (compact size).

Video Standard: Supports PAL/NTSC video formats.

Number of Channels: 8 channels.

Channel Selection: Short press the frequency button to switch channels.

Transmission Frequency: 8CH (refer to the frequency table below).

Transmission Power: Maximum 30dBm ±1dBm.

Power Adjustment: Short press the power button to switch between four power levels: 25mW, 200mW, 400mW, and 1000mW.

Antenna Interface: MMCX connector.

Modulation Type: FM (Frequency Modulation).

Frequency Table:
